Netbird (VPN IT Infrastructure mit Wireguard und authentik)
Als Client am Beispiel mit Paperless-AI:
services:
paperless-ai:
image: clusterzx/paperless-ai:3.0.9
container_name: paperless-ai
#network_mode: host
depends_on:
- netbird
restart: unless-stopped
cap_drop:
- ALL
security_opt:
- no-new-privileges=true
environment:
- PUID=1000
- PGID=1000
- PAPERLESS_AI_PORT=${PAPERLESS_AI_PORT:-3000}
- RAG_SERVICE_URL=http://localhost:8000
- RAG_SERVICE_ENABLED=true
- PAPERLESS_URL=https://paperless-ai.MEINEDOMAIN.de
ports:
- "3057:${PAPERLESS_AI_PORT:-3000}"
volumes:
- data:/app/data
netbird:
image: netbirdio/netbird:latest
container_name: paperless-ai-netbird
hostname: fn-paperless-ai
privileged: true
#network_mode: host
cap_add:
- NET_ADMIN
- SYS_ADMIN
- SYS_RESOURCE
volumes:
#- /var/run/netbird:/var/run/netbird
- nb-var-lib:/var/lib/netbird
- nb-cfg:/etc/netbird
environment:
- NB_SETUP_KEY=FFE.........AA49
restart: unless-stopped
volumes:
data:
nb-cfg:
nb-var-lib:Falls netbird up nicht richtig connectet:
sudo systemctl stop netbird
sudo systemctl disable netbird
sudo rm -rf /usr/local/bin/netbird
sudo rm -rf /etc/netbird
sudo rm -rf /var/lib/netbird
sudo apt remove netbird -y
curl -fsSL https://pkgs.netbird.io/install.sh | sudo bash
sudo apt update
sudo apt install netbird -y
# netbird up --allow-server-ssh --enable-ssh-root --setup-key ABC-123-DEF-456ohne sudo
systemctl stop netbird
systemctl disable netbird
rm -rf /usr/local/bin/netbird
rm -rf /etc/netbird
rm -rf /var/lib/netbird
apt remove netbird -y
curl -fsSL https://pkgs.netbird.io/install.sh | bash
apt update
apt install netbird -y
# netbird up
# netbird up --allow-server-ssh --enable-ssh-root --setup-key ABC-123-DEF-456
Troubleshooting
Fremdes Subnetz nicht erreichbar
Falls eine IP-Adresse aus einem anderen Subnetz nicht erreichbar ist, kann es daran liegen, dass eine Docker-Bridge mit diesem Subnetz vorhanden ist.
Beispiel: Von einem Hetzner Server möchte ich das Subnetz 192.168.5.0/24 erreichen. Der Ping klappt nicht.
Debuggen mit
ip route get 192.168.5.55ergibt zb
root@fn-01:~# ip route get 192.168.5.55
192.168.5.55 dev br-ebe13ac6d23b src 192.168.0.1 uid 0 cache
weiteres debugging:
# Netbird Status
netbird status --detail
# Routing-Tabelle analysieren
ip route show
ip route get 192.168.5.55
# ergibt zb
# root@fn-01:~# ip route get 192.168.5.55
# 192.168.5.55 dev br-ebe13ac6d23b src 192.168.0.1 uid 0 cache
# ^^^^ DA IST DER FEHLER, die Docker-Netzwerk-Bridge br-ebe13ac6d23b sorgt für das Routing und schlägt damit fehl
# Netbird Interface prüfen
ip addr show wt0
sudo iptables -L -v -n | grep -A 10 wt0
# Netbird logs
sudo journalctl -u netbird -f
sudo systemctl status netbird
# Ping mit Details
ping -I wt0 192.168.5.55
traceroute 192.168.5.55
docker network lsergibt
root@fn-01:~# docker network ls
NETWORK ID NAME DRIVER SCOPE
396e4a7a02a8 backrest_default bridge local
9f3a5b5f9017 beszel_default bridge local
7ff0d869b3a9 bitwarden_default bridge local
944ac8eea6b1 bridge bridge local
8a7ecea723cd bs_default bridge local
56847cda68c7 heimdall_default bridge local
23c9d0945209 host host local
dc6107d2a414 nextcloud-aio bridge local
10cf7e670c62 nextcloud_default bridge local
4918f3559a98 nginx_lowqart_default bridge local
1e7aaa5ae6b2 none null local
6703ef3d8a62 ollama_default bridge local
15659627c007 paperless-ai_default bridge local
f02f912a0898 paperless_default bridge local
e29d199145fc reverseproxy_network bridge local
9e294e453ecb semaphore_default bridge local
f1dde6f30b1f shlink_default bridge local
c7750a87eef4 syncthing_default bridge local
f0e08f4a4c7c uptimekuma_default bridge local
c85d048db1b1 vikunja_default bridge local
57cd332f96b1 windmill_default bridge local
ebe13ac6d23b zerobyte_default bridge local
# ^^^ fehlerhafte bridgedocker network inspect ebe13ac6d23bergebnis: die docker network bridge nimmt 192.168.0.0/20 als subnet, was 192.168.5.0/24 inkludiert.
lösung für die Problem-Bridge:
docker-compose von zb zerobyte
...
- /var/lib/docker:/backup-var-lib
- /mnt/fn-volume-01:/backup-fn-volume-01
networks:
- zerobyte_network # <<< wichtig
volumes:
app:
networks:
zerobyte_network:
driver: bridge
ipam:
config:
- subnet: 172.69.19.0/24
gateway: 172.69.19.1danach wird die alte bridge mit 192.168.0.0/20 gelöscht und eine neue mit subnet 172.69.19.0/24 erstellt.
Dauerhafte lösung: siehe https://wiki.folkerts.it/books/docker/page/ip-kollidierung-bei-netbird-verhindern-192168x-und-101x
nano /etc/docker/daemon.json
{
"default-address-pools": [
{
"base": "172.16.0.0/12",
"size": 20
}
],
"data-root": "/mnt/fn-volume-01/docker-data",
"log-opts": {
"max-size": "100m",
"max-file": "5"
}
}sudo systemctl restart dockerNetbird Cloud auf Unifi-Gateway installieren
https://git.shivering-isles.com/-/snippets/22
install.sh
#!/bin/bash
set -e
if test $(ubnt-device-info firmware) \< "3.0.0"; then
echo "Try the other UDM setup script for 1.x: https://git.shivering-isles.com/-/snippets/19" >&2
exit 1
fi
mkdir -p /data/netbird
cd /data/netbird
if [[ -e ./netbird ]]; then
mv ./netbird ./netbird.old
fi
NETBIRD_VERSION="$(curl -s https://api.github.com/repos/netbirdio/netbird/releases/latest | jq -r ".tag_name")"
curl -L https://github.com/netbirdio/netbird/releases/download/${NETBIRD_VERSION}/netbird_${NETBIRD_VERSION//v}_linux_arm64.tar.gz | tar xvzf -
./netbird service install || true # ignore error since it'll fail if it's already installed
# Due to outdated kernels by unifi, this is required otherwise newer versions of netbird fail to start
mkdir -p /etc/systemd/system/netbird.service.d/
cat >/etc/systemd/system/netbird.service.d/legacy.conf <<EOF
[Service]
Environment="NB_USE_LEGACY_ROUTING=true"
Environment="NB_DISABLE_CUSTOM_ROUTING=true"
EOF
systemctl daemon-reload
if systemctl is-active netbird.service; then
systemctl restart netbird.service
fi
if ! systemctl is-enabled netbird.service; then
systemctl enable --now netbird.service
fi
danach
chmod +x install.sh
./install.sh
curl -fsSL https://pkgs.netbird.io/install.sh | sh
/data/netbird/netbird -k <setup key> upNetbird als Management-Server selbst hosten
Dieses Tutorial funktioniert noch nicht zu 100%. Ich bleibe immer bei netbird.domain.de/peers mit Ladeloop hängen
Links zum Problem:
https://github.com/netbirdio/netbird/issues/3110 Client failed to connect to Self-Hosted NetBird server: failed while getting Management Service public key
https://github.com/netbirdio/netbird/issues/3007 Stuck on loading screen on "/peers" (Authentik)
https://github.com/netbirdio/netbird/issues/3007#issuecomment-2764264829 < hat geholfen
https://github.com/netbirdio/netbird/issues/3007#issuecomment-2564843380 < nginx-pm cfg
https://github.com/netbirdio/netbird/issues/2941 Request failed with status code 401 (Authentik) < scope api access & redirects
https://github.com/netbirdio/netbird/issues/2515 Unable to authenticate with Authentik SSO
https://github.com/netbirdio/netbird/issues/2510 Netbird with NGiNX Proxy Manager and Authentik
https://github.com/netbirdio/netbird/issues/2338 Can't access dashboard - Token Invalid, Authentik
https://github.com/netbirdio/netbird/issues/2043 error: failed while getting Management Service public key
https://github.com/netbirdio/netbird/issues/2043#issuecomment-2384470230 < nginx-pm cfg
https://github.com/netbirdio/netbird/issues/1962 netbird dashboard does not open properly
https://github.com/netbirdio/netbird/issues/1742 NGINX reverse proxy question
https://github.com/netbirdio/netbird/issues/1250 Authentik login not working: Login Error: User state: Unauthenticated
https://github.com/netbirdio/netbird/issues/536 Run netbird behind reverse proxy
https://docs.netbird.io/selfhosted/selfhosted-guide#step-2-prepare-configuration-files
https://docs.netbird.io/selfhosted/identity-providers#authentik
Folge dieser Anleitung: https://docs.netbird.io/selfhosted/selfhosted-guide
Es wird ein Skript zur Verfügung gestellt, mit dem man eine docker-compose.yml nach eigenen Wünschen aus template Dateien erzeugen kann.
Anleitung ganz genau lesen!
VIDEO DAZU: https://www.youtube.com/watch?v=QQaRB1vL6Q8
Vorschlag für NGINX Proxy Manager Advanced cfg aus gh issue https://github.com/netbirdio/netbird/issues/3110#issuecomment-2567362588
# This is necessary so that grpc connections do not get closed early
# see https://stackoverflow.com/a/67805465
client_header_timeout 1d;
client_body_timeout 1d;
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header X-Scheme $scheme;
proxy_set_header X-Forwarded-Proto https;
proxy_set_header X-Forwarded-Host $host;
grpc_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header Authorization $http_authorization;
grpc_set_header Authorization $http_authorization;
# Proxy dashboard
location / {
proxy_pass http://nb-dashboard:80;
}
# Proxy Signal
location /signalexchange.SignalExchange/ {
grpc_pass grpc://nb-signal:80;
grpc_set_header Authorization $http_authorization;
grpc_ssl_verify off;
grpc_read_timeout 1d;
grpc_send_timeout 1d;
grpc_socket_keepalive on;
}
# Proxy Management http endpoint
location /api {
proxy_pass http://nb-management:443;
}
# Proxy Management grpc endpoint
location /management.ManagementService/ {
grpc_pass grpc://nb-management:443;
grpc_set_header Authorization $http_authorization;
grpc_ssl_verify off;
grpc_read_timeout 1d;
grpc_send_timeout 1d;
grpc_socket_keepalive on;
}
